1-2 Specification
Spec Description
Design
∗
Micro ATX form factor 4 layers PCB size: 24.4x18.0cm
Chipset
∗
VIA P4M266A(CE) North Bridge Chipset
∗
VIA VT8235 South Bridge Chipset
CPU Socket
(mPGA478B Socket)
∗
Support Intel Pentium 4 478 Pin package utilizes Flip-Chip Pin
Grid Array (FC-PGA2) package processor
∗
Support 1.5G
∼
3.2G 478 Pin Pentium 4 processor
∗ Support Hyper Threading /Prescott CPU
∗
Reserves support for future Intel Pentium 4 processors
Memory Socket
∗
184-pin DDR Module socket x 2
∗
Support 2 pcs DDR266/DDR200 DDR Modules Expandable to
2.0GB
Expansion Slot
∗
AGP slot x1 support AGP 2.0 & 4X mode
∗
32-bit PCI slot x2
Integrate IDE
∗
Two PCI IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100/133 functions that
deliver the data transfer rate up to 133 MB/s
VGA
∗
Integrated High Performance & High Quality 3D Accelerator
∗
Support Ultra-AGPII with 2GB/s bandwidth
∗
Built-in programmable 24-bit true-color RAMDAC up to
250MHz pixel clock
∗
Programmable frame buffer size from 8MB and up to 32MB.
LAN
(Only for PM2MP
)
∗
Support Fast Ethernet LAN function provide 10/100 Mb/s data
transfer rate
Audio
∗
AC’97 Digital Audio controller integrated
∗
6-channel AC’97 Audio CODEC on board
∗
Audio driver and utility included
BIOS
∗
Award 2MB Flash ROM
Multi I/O
∗
PS/2 keyboard and PS/2 mouse connectors
∗
Floppy disk drive connector x1
∗
Parallel port x1
∗
Serial port x1
∗
USB2.0 port x4 and headers x 2 (connecting cable option)
∗
Audio connector (Line-in, Line-out, MIC )
