5
Jumpers
Jumper Name Description Page
JBAT
CMOS RAM Clear
3-pin Block P.6
JP1
Keyboard Power On Enable/Disabled
3-pin Block P.7
JP3/JP4
USB Power On Enable/Disabled
3-pin Block P.7
Connectors
Connector Name Description Page
ATXPWR ATX Power Connector 20-pin Block P.11
ATX12V ATX 12V Power Connector 4-pin Block P.12
PS2KBMS PS/2 Mouse & PS/2 Keyboard
Connector
6-pin Female P.12
USB/USB1 USB Port Connector 4-pin Connector P.12
LAN LAN Port Connector RJ-45 Connector P.12
PARALLEL Parallel Port Connector 25-pin Female P.12
AUDIO Audio Connector 3 phone jack Connector P.12
COM1 Serial Port COM1 Connector 9-pin Connector P.12
VGA VGA Connector
15-pin Female
P.13
FDD Floppy Driver Connector 34-pin Block P.13
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.13
for PM2MP Only
Headers
Header Name Description Page
AUDIO SPEAKER, MIC header 9-pin Block P.14
USB2 USB Port Headers 9-pin Block P.14
HD LED IDE activity LED 2-pin Block P.15
RESET Reset switch lead 2-pin Block P.15
SPEAK PC Speaker connector 4-pin Block P.15
PWR LED Power LED 2-pin Block P.15
PWR BTN Power switch 2-pin Block P.15
SYSFAN, CPUFAN FAN Headers 3-pin Block P.16
CD
_
IN CD Audio-In Headers 4-pin Block P.16
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket 478 Pin CPU Socket 478-pin mPGA CPU Socket P.8
DDR1, DDR2 DDR Module Socket 184-pin DDR Module Socket P.9
PCI1, PCI2 PCI Slot 32-bit PCI Local Bus Expansion slots P.10
AGP AGP 4X Mode Slot AGP Expansion Slot P.11
