JGaurora A5 User Manual

While waiting for the nozzle to heat, you can install the onboard filament holder
After the extruder nozzle has finished preheating, filament can then be fed into the filament inlet port at the bottom
of the filament drive assembly, as shown in the pictures below. It is recommended to straighten the filament before
insertion.
Note：For smooth operation, ensure the spool is installed correctly, so that it rotates clockwise during printing.
Install filament
holder at the
right side of
frame
Press down the sliding
pressure block on the left
side of the feeding
component, and then put
the straight and f l at
filament into the feeding
mouth
Click [ADD] to
increase nozzle
temp. to 200’C
14

JGaurora A5 Specifications

General

Build Volume	305 x 305 x 320 mm
Layer Resolution	0.05 - 0.3 mm
Print Speed	10 - 150 mm/s
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Connectivity	USB, SD Card
Frame Material	Aluminum
Print Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Bed Temperature	Up to 110°C
Nozzle Temperature	Up to 250°C
Supported Materials	PLA, ABS
Display	LCD
Power Supply	110V / 220V
