JGaurora A5 User Manual

4.5 Trial printing
1) Model loading: Select and load t he 3d file you want to print, or drag it directly into the software window.
2) G-code save: After slicing of the 3d file is finished, click the “Save to File” button in the lower right corner to save
Click [IN] once
nozzle temp.
reaches 200ºC
When the filament
comes out of the
nozzle, l o ading
is completed.
Click
“
Open File
”
15

JGaurora A5 Specifications

General

Build Volume	305 x 305 x 320 mm
Layer Resolution	0.05 - 0.3 mm
Print Speed	10 - 150 mm/s
Nozzle Diameter	0.4 mm
Filament Diameter	1.75 mm
Connectivity	USB, SD Card
Frame Material	Aluminum
Print Technology	FDM (Fused Deposition Modeling)
Heated Bed	Yes
Bed Temperature	Up to 110°C
Nozzle Temperature	Up to 250°C
Supported Materials	PLA, ABS
Display	LCD
Power Supply	110V / 220V
