Jianken JGL-80/2.2R24-20 User Manual

Service hotline ： +86 523-84385453
- 10 -
3. 3
、
Connection diagram of encoder
JGY motor spindle needs special permanent magnet synchronous
driver. Common inverters can not drive it.
Regarding the installation and maintenance of JGY motor spindle,
please refer to JGL motor spindle.
Model
Overall dimensions
N.W
（kg)
D
D1
D2
D3
D4
D5
L
L1
L2
N-d1
JGY-80/3.7R24-ISO20
80
28
72
-
-
102
170
7
126
-
10
JGY-100/5.5R15-24-BT30
100
38
72
99.9
220
8
114
14
JGY-110/7.5R12-24-BT30
110
38
92
-
-
110
228
12.5
152
-
19
JGY-120/10R13-24-T30
120
42
120
140
158
120
190
93
165
6-φ8.
5
26
JGY-150/15R7.5-20-T40
150
63
148
168
185
149.8
223
24
200
8-φ8.
5
55
