Jianken JGL-80/2.2R24-20 User Manual

Service hotline ： +86 523-84385453
- 1 -
1. Tips
It’s necessary to match the high speed spindle motor with
inverter. No allowing directly plugging the spindle motor to the power
supply. Otherwise, it will damage the high-speed spindle directly.
Before the inverter drives the spindle, all the parameters must be
set up correctly. Wrong settings will also damage the spindle motor.
2. JGL Pneumatic Tool Change Spindle Motor
JGL series is the high precise automatic tool change spindle motor,
drove by inverter, which can continuously adjust the spindle speed by
controlling the frequency. It has the characteristics of low noise, stable
and reliable operation, fast tool changing and high precision of repeated
tool change. It’s mainly used for high speed drilling, grinding and
engraving in machining centers. During the machining, the tool can be
changed automatically by the air cylinder on the spindle and CNC
controlling on the machine, which improves the machining efficiency.
2.1、Specifications
models
Speed
(r/min)
Motor parameters
Lub
mode
Inter
face
cool
Note
power
(kW)
Volt
(V)
Freq
(HZ)
Cur
(A)
JGL-62/1.8R60
60000
1.8
220
1000
4.5
grease
263504
water
with unclamp
& clamp unit
JGL-62/1.8R60-10
60000
1.8
220
1000
4.5
grease
ISO10
water
with unclamp
& clamp unit
JGL-80/1.5R24-20
24000
1.5
220
400
4.2
grease
ISO20
water
with sensor
unclamp &
clamp unit
JGL-80/2.2R24-20
24000
2.2
220
400
6
grease
ISO20
water
with sensor
unclamp &
clamp unit
JGL-80/2.2R30-20
30000
2.2
220
500
6
grease
ISO20
water
with sensor
unclamp &
clamp unit
