Jimi JM01 - LED Status Indicators and Wiring; Red LED (Power;Working Status); Blue LED (GPS Signal Status); Green LED (GSM Signal Status)

3 LED status indicator and wiring
3.1 Red LED (power/working status indicator)
Status Meaning
Quick ashing Low battery
Slow ashing Fully charged
Continuously in bright Charging
Continuously in dark No battery/troubleshoot
3.2 Blue LED (GPS signal indicator)
Status Meaning
Quick ashing Searching GPS signal
Slow ashing GPS signal has successfully
Continuously in dark GPS stops working
3.3 Green LED (GSM signal indicator)
Status Meaning
Quick ashing GSM initialization
Slow ashing GPRS online
Continuously in dark No GSM signal or no SIM card installed
