4.5 Power/ACC/Tele-cut off(petrol/electricity) control cable (4 pin)
1. Device standard power supply 9V-36V DC, please use the original factory
supply power cord, red is positive, black is negative. During installation, power
negative please should be independently grounded, do not connect with other
ground wire.
2. The ACC line(orange) connects to ACC switch of the vehicle. Please make sure
to connect the ACC wire; otherwise the device will enter ignition detection status
when disconnect the ACC line. If you don’t need to anti-theft temporarily, just
connect the ACC line to the positive side in parallel.
3. Tele-cutoff(petrol/electricity) control line(yellow) is connected to pin 86 of the
Tele-cutoff (petrol/electricity) relay (equal to the yellow line of the relay socket).
5. Quick Operation Instructions
To properly use the device, common parameters should be set before
initial use. This can be done by using the parameter editor or by sending SMS
commands to the device. (“,”should be English comma and no space
before and after the comma)
