JIYI K3-A - AB-MODE Operation

JIYI Robotics CO. Ltd
16
CH2
Control the pitch of
roll angle
Different from GPS-angle mode, the stick
couldn’t control the pitch angle of the
aircraft any more, but strictly controls the
flight speed of the aircraft in pitch
direction.
CH3
Control speed of altitude
When the throttle is in the middle, the
aircraft stays in constant altitude.
CH4
Control the rate of yaw
To change the desire rate of pitch angle
5.1.5 AB-MODE
1、Setting
Before using the mode, you need connect to the Assistant2 Software for some
channel setting.
Settings of AB record: connect to Assistant2 Software and enter the path of
“Adv”—“Plant”. Read AB operation process.
Gear 1: close
Gear 2: record A
Gear 3: record B
AB record
channel value
p<=1200
1400<=p<=1600
p>=1800
