SECTION II
SPECIFICATIONS
A. SPECIFICATIONS
Shaded areas are stated in metric equivalents 10/8/03
* A reversing dryer is available with 3-phase (3ø) 1/2 hp (0.373 kW) motors standard.
** Size of piping to dryer varies with installation conditions. Contact factory for assistance.
*** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system must be
provided with clean, dry, and regulated 80 psi +/- 10 psi (5.51 bar +/- 0.68 bar) air supply.
NOTE: Manufacturer reserves the right to make changes in specifications at any time without notice or
obligation.
GasElectric
Steam***
BASKET (TUMBLER) DIAMETER 32-3/4”
83.2 cm
BASKET (TUMBLER) DEPTH 19”
48.3 cm
BASKET (TUMBLER) MOTOR 1/2 hp*
0.373 kW
DOOR OPENING (DIAMETER) 21-1/2”
54.61 cm
BASKET (TUMBLER) VOLUME 9.26 cu ft
0.262 cu m
AIRFLOW (60 Hz) 460 cfm
13.02 cmm
AIRFLOW (50 Hz) 386 cfm
10.93 cmm
DRYERS PER 20’/40’ CONTAINER 14/30
DRYERS PER 45’/48’ TRUCK 45/45
S.A.F.E. WATER CONNECTION 3/4” M.N.P.T.
VOLTAGE AVAILABLE 120-460v 1ø - 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 407 lbs
184.6 kg
APPROX. WEIGHT (CRATED) 446 lbs
202.1 kg
HEAT INPUT 78,000 Btu/hr
19,656 kcal/hr
INLET PIPE CONNECTION 1/2” F.B.S.P.T.**
OVEN SIZE
kW
Btu/hr
(60 Hz)
kcal/hr
(50 Hz)
15 51,194
12,901
20 68,258
17,201
24 81,910
20,641
VOLTAGE AVAILABLE 120-460v 1ø - 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 435 lbs
197.3 kg
APPROX. WEIGHT (CRATED) 474 lbs
214.8 kg
COMPRESSED AIR VOLUME 0.75 cfh
0.02 cmh
STEAM CONSUMPTION 98.8 lbs/hr
44.8 kg/hr
OPERATING PRESSURE 125 psi max
8.6 bar
BOILER HP NORMAL LOAD 2.9
AIR CONNECTION 1/8” F.N.P.T.
SUPPLY CONNECTION 1” F.N.P.T.
RETURN CONNECTION 1” F.N.P.T.
