* 3-Wire is available. 10/9/03
IMPORTANT: 3-phase (3ø) figures shown are for a 3-wire service only.
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse
value, by applying either local and/or National Electrical Codes to
listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For
others, calculate/verify correct breaker size according to appliance amp
draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
15 kW ELECTRIC
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
208 1ø 2 77 – 100
230/240 1ø 2 67 68 90
380 3ø 4* – 28 35
20 kW ELECTRIC
208 1ø 2 101 – 125
230/240 1ø 2 88 89 125
380 3ø 4* – 36 45
24 kW ELECTRIC
208 3ø 3 72 – 90
230/240 3ø 3 63 63 80
416 3ø 4* – 39 50
460 3ø 3 32 – 50
b. Electric Models Only
ALL electrically heated dryers must be connected to the electric service shown on the dryer’s data
label. The connecting wires must be properly sized to handle the rated current.
