GAS AND STEAM
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
NOTES
: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
When fuses are used they must be dual element, time delay, current
limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse value,
by applying either local and/or National Electrical Codes to listed
appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY.
For others, calculate/verify correct breaker size according to appliance
amp draw rating and type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
120 1ø 2 13 — 20
208 1ø 2 7.6 — 15
220 1ø 2 7.3 8.6 15
230 1ø 2 — 8 15
240 1ø 2 7 8 15
208 3ø 3 4.7 — 15
220 3ø 3 4.8 4.8 15
230 3ø 3 — 4.7 15
240 3ø 3 4.9 5.4 15
380 3ø 3 2.9 — 15
400 3ø 3 3 — 15
380 / 416 3ø 4 or 3 — 3.1 15
400 3ø 4 or 3 — 3.2 15
440 3ø 3 2.6 — 15
460 / 480 3ø 3 2.8 — 15
2. Electrical Service Specifications
IMPORTANT: Figures shown are for non-reversing models only. For reversing models contact the
factory.
a. Gas and Steam Models Only
Check your local code for breaker and wire size 5/19/15
