JLG DSP S - 6.3 Operator Maintenance; Lubrication; Hydraulic Oil Specifications - Standard

SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-6 – JLG Lift – 31210284
6.3 OPERATOR MAINTENANCE
Lubrication
Hydraulic Oil (HO)
NOTE: Aside from JLG recommendations, it is not advisable to mix oils
of different brands or types, as they may not contain the same
required additives or be of comparable viscosities.
Table 6-7. Hydraulic Oil Specifications - Standard
SPECIFICATION
NERVOFLUID VG
15
MOBIL DTE
10 XL15
ISO Viscosity grade 15 15
Cinematic Viscosity @ +40°C (104°F) 14.9 mm²/s (cSt) 15.8 mm²/s (cSt)
Cinematic Viscosity @
+100°C (212°F)
3.8 mm²/s (cSt) 4.07 mm²/s (cSt)
Pour Point, Max. -40°C (-40°F) -54°C (-65°F)
Flash Point, Min. 175°C (347°F) 182°C (359°F)
Viscosity Index 153 168
ISO 6743-4 Classification HV -
