JLG LiftPod FT140 User Manual (English)

Questions and Answers:

S
Sharon CrawfordAug 12, 2025
What to do if the JLG LiftPod FT140 Lifting Systems platform doesn't lift from the bottom but the motor starts?
- J
  Jodi MorseAug 12, 2025
  If the JLG Lifting Systems platform doesn't lift up from the bottom, and the motor starts, it might be due to the driveshaft interlock being engaged. To solve this, firmly push the cordless drill on the driveshaft down to disengage the safety interlock. If you are using a powerpack, ensure it is correctly fitted to the platform, the latch is down, and the drive shaft is connected. Also, check that the emergency stop button is disengaged by turning it clockwise until it pops up.
N
Neil FrancisAug 16, 2025
What to do if the JLG Lifting Systems platform won't move when elevated, but the motor starts?
- K
  Kimberly RamosAug 16, 2025
  If the JLG Lifting Systems platform will not move when elevated but the motor starts, the powerpack shaft may not be engaged. Ensure the powerpack is charged, correctly fitted, fully down, and latched. If the issue persists, it could be a drive shaft malfunction, in which case you should lower the platform using the manual descent procedure and refer to an Authorized JLG Service Center.
I
Isaac ThompsonAug 19, 2025
Why won't the powerpack motor start on my JLG Lifting Systems?
- D
  Dustin JamesAug 20, 2025
  If the optional powerpack motor on your JLG Lifting Systems does not start, first check if the emergency stop button is engaged (pushed in). If it is, disengage it by turning it clockwise until it pops up. Also, ensure that you are activating the direction selector or enable button correctly by pressing and holding the enable button, then pressing and holding the 'UP' button continuously until you reach the desired height. Furthermore, make sure a charged battery is properly installed in the powerpack. Finally, the motor may have overheated; wait until it cools down, as the temperature cutout resets automatically. Alternatively, use the manual descent procedure to lower the platform.
T
Terry VaughnAug 25, 2025
What to do if JLG LiftPod FT140 platform won't lift the full rated load?
- C
  Christopher BrownAug 25, 2025
  If your JLG Lifting Systems platform won't lift the full rated load, the battery might not be fully charged. Try charging or replacing the battery. If the problem persists, the drive clutch may be slipping, and you should contact an Authorized JLG Service Center.
J
Jamie CooperAug 27, 2025
Why will the base of my JLG LiftPod FT140 not level?
- R
  raymond86Aug 27, 2025
  If the base of your JLG Lifting Systems will not level, which is critical before elevating, especially on the FT70 model, it might be due to the castor being deployed. With no load on the platform and ensuring people are clear of the adjustable feet, apply approximately 55 ft. lb. (25Kg) of pressure to the front of the base to retract the castor. Afterward, you should be able to use the adjustable feet to level the machine on slopes less than 2 degrees front to back. Remember, never use the machine on any side slope.
J
Juan NunezAug 31, 2025
How to fix a JLG Lifting Systems machine that does not wheel properly?
- S
  Sarah AndrewsAug 31, 2025
  If your JLG Lifting Systems machine does not wheel properly, it could be due to the retractable swivel castor not being properly deployed. Ensure there is no load on the platform or base, then lift the castor deploy handle on the front of the base, next to the platform gate. The castor should deploy, lifting the front of the machine off the adjustable feet, allowing it to roll easily. Alternatively, the castor might be damaged and needs replacement.
Z
Zachary SchmittSep 4, 2025
Why does my JLG LiftPod FT140 Lifting Systems machine rock slightly side to side?
- C
  Carlos McgrathSep 4, 2025
  If your JLG Lifting Systems machine rocks slightly side to side, it's likely because the support surface isn't level. Ensure you're only using the machine on firm and level surfaces. Also, check that the adjustable feet or castors are both in contact with the supporting surface, adjusting the feet as needed to ensure firm contact and a level machine.
K
Kyle MarshallSep 7, 2025
How to assemble JLG LiftPod FT140 if it does not assemble properly?
- M
  mkirbySep 7, 2025
  If the JLG Lifting Systems machine does not assemble properly, check that each component and assembly alignment is correct. Additionally, ensure the platform is fully engaged by checking the alignment and sliding parts until the platform latch is properly engaged.

JLG LiftPod FT140 Specifications

General

Platform Height	14 ft
Platform Capacity	330 lb (149.7 kg)
Machine Width	2 ft 6 in (0.76 m)
Machine Length	6 ft 7 in (2.01 m)
Platform Width	2 ft 2 in (0.66 m)
Lift Capacity	330 lb (149.7 kg)
Weight Capacity	330 lb (149.7 kg)
Battery	12V DC
Charger	12V DC
Overall Length	6 ft 7 in (2.01 m)
Overall Width	48 in
Overall Height	3 ft 10 in (1.17 m)

Summary

Operation, Safety, Service and Maintenance Manual

LiftPod Models FT70 and FT140

Identifies the specific LiftPod models covered by this manual.

Safety Warnings and Precautions

Safety Alert Symbols and Signal Words

Safety Compliance and Reporting

Section 1: Safety Precautions

Operator Training and Knowledge

Emphasizes reading the manual and obtaining adequate training.

Machine Inspection Requirements

Specifies requirements for machine inspection before operation.

General Operation Safety

Covers attentiveness, proper use, and avoiding malfunctions during operation.

Trip and Fall Hazard Prevention

Provides guidelines on preventing trips and falls, including lanyard use.

Electrocution Hazard and Approach Distances

Details electrocution hazards and minimum approach distances to electrical lines.

Tipping Hazard Prevention

Covers precautions against tipping hazards related to ground conditions and slopes.

Crushing and Collision Hazard Safety

Provides safety measures to prevent crushing and collision incidents.

Battery Safety Hazards

Covers safety precautions and hazards related to batteries.

Maintenance Safety Precautions

Outlines general safety precautions to be observed during maintenance.

Section 2: Preparation and Inspection

Personnel Training Requirements

Specifies the necessary training for operating and maintaining the aerial platform.

Inspection and Maintenance Schedule

Details periodic machine inspections and maintenance recommended by JLG.

Daily Walk-Around Inspection

Provides instructions for conducting a daily walk-around inspection.

Walk-Around Inspection Components (Sheet 1)

Details inspection points for the base frame, mast assemblies, and platform latch.

Walk-Around Inspection Components (Sheet 2)

Details inspection points for castors, descent crank, platform, tool tray, and powerpack.

Function Check Procedures

Details the steps for performing a function check of all machine systems.

Section 3: Machine Operation

Base Frame Component Details

Detailed description and diagrams of FT70 and FT140 base frame components.

Platform and Mast Components

Diagrams illustrating platform and mast components for LiftPod models.

General Machine Assembly

Provides general safety notices and capacity information for machine assembly.

Mast Mount (Stump) Installation

Details the procedure for installing the mast mount (stump) onto the base.

Platform to Mast Installation Details

Details on attaching the platform to the mast, including latch engagement.

Power Pack Control Unit Installation (FT70)

Instructions for installing the power pack control unit on FT70.

Positioning and Leveling the Machine

Guides on positioning the machine and using the bubble level for leveling.

Entering and Exiting the Platform Safely

Provides safety guidelines for entering and exiting the platform.

Platform Operation with Cordless Drill

Details on operating the platform using a cordless drill.

Cordless Drill Controls and Operation

Explains cordless drill controls, torque settings, and operation.

Power Pack Control Unit Operation

Instructions for operating the platform using the power pack control unit.

Transport and Maneuvering General

Parking and Storage Guidelines

Power Pack Control Unit Overview

Power Pack Control Functions

Explanation of emergency stop, mast select, enable, UP/DOWN buttons, and LED indicators.

Power Pack Connectors and Battery

Battery Operation and Removal

Battery Charge Status Indicators

Manual Descent Tool Operation

Fully Assembled Maneuvering

Vehicle Transport Procedures

Section 4: Emergency Procedures

Manual Descent Tool Overview

Platform Manual Descent Operation

Step-by-step guide for lowering the platform using the manual descent crank.

Ground Manual Descent Operation

Procedure for ground personnel to lower the platform using the telescoping tool.

Handling Platform Entrapment

Platform Will Not Lower Troubleshooting

Incident Notification Protocol

Section 5: General Specifications

Platform Data and Capacities

Machine Component Weights

Machine Specifications Overview

Presents key specifications for FT70 and FT140 models in a table.

Powerpack Electrical Specifications

Decal Replacement Procedures

Section 6: Service, Maintenance and Replacement Parts

Introduction to Maintenance Safety

General Maintenance Safety Precautions

Machine Preparation and Inspection

Preventive Maintenance and Inspection Schedule

Outlines the schedule for preventive maintenance and periodic inspections.

Maintenance and Inspection Schedule Details

Presents the detailed preventive maintenance and inspection schedule table.

Maintenance Schedule Codes and Notes

Inspection and Maintenance Codes Explained

Servicing and Maintenance Guidelines

Mast Component Overview

Relieving Gas Strut Cylinder Pressure

Crucial safety procedure to relieve pressure before mast disassembly.

Gas Strut Pressure Relief Steps

Removing the Mast Top Cap

Outer-Mast Section Gas Strut Removal

Gearbox Removal Procedure

Mast Assembly Reassembly

Mast Drive Screw Lubrication Procedure

Details lubrication of mast drive screws and access points.

Mid-Mast Drive Screw Lubrication

FT140 Base Frame Replacement Parts

Mast Replacement Parts Kits

Platform Replacement Parts Kits

Power Pack and Tool Tray Replacement Parts

FT140 Base Frame Service Kit Locations

FT70 Base Frame Service Kit Locations

Platform Component Service Kit Locations

Accessory Components Service Kit Overview

Pre-Start Inspection Procedures

Outer-Mast Drive Screw Lubrication

FT70 Base Frame Replacement Parts

Accessory Replacement Parts Kits

Section 7: Troubleshooting

General Troubleshooting Information

Provides guidance on locating and correcting operating problems.

Troubleshooting: Assembly and Powerpack Issues

Addresses issues with assembly, powerpack start, and initial lift.

Troubleshooting: Mobility and Leveling Issues

Covers issues with machine mobility, castor deployment, and leveling.

Troubleshooting: Stability and Load Issues

Addresses machine rocking, surface contact, and lifting rated load issues.
