VL-3E-1 Pilot Operating Handbook
date of issue:
26/39
4.3.15 Balked landing or „go around“
1. Throttle - full
2. Engine speed - 5700 rpm
3. Flaps - set at the "15°" position at a speed of 90 km/h (50 kts)
4. Trim - as necessary
5. Flaps - retract at a height of 50 m (165 ft)
6. Trim - as necessary
7. Engine speed - maximal continuos power
8. Instruments - within limits
9. Climb - at 120 km/h (65 kts)
10. Landing gear - go to the up position
4.3.16 After landing
Engine speed - set as necessary for taxiing
Flaps - retracted and locked
Trim - neutral position
4.3.17 Engine shut-down
1. Engine speed - idling
2. Instruments - engine instruments within limits
3. COMM + intercom- off
4. Ignition - off
5. Circuit breakers - off
6. Avionic master switch - off
7. Ignition box - turn the key to switch off
8. Fuel valve - off
4.3.18 Flight in rain
When flying in the rain, no additional steps are required. Aeroplane qualities and performance are not
substantially changed
