VL-3E-1 Pilot Operating Handbook
date of issue:
7/39
1.3.2 Basic Technical data
Wing
span …………………………………………… 8.44 m
area of wing …………………………………… 9.8 m
2
M.A.C. …………………………………………. 1,236 m
loading …………………………………………. 46 kg/m
2
Ailerons
area ……………………………………………... 0.207 m
2
Flaps
area ……………………………………………… 0.8 m
2
Fuselage
length ..…………………………………………… 6.2 m
width …………………………………………….. 1.15 m
height …………………………………………….. 1.5 m
Horizontal tail unit
span …………………………………………….. 2.68 m
area ……………………………………………… 1.69 m
2
elevátor area …………….. ………………......... 0.73 m
2
Vertical tail unit
height …………………………………………… 1.03 m
area …………………………….……………….. 0.876 m
2
rudder area …………………………………….. .0.309 m
2
Landing gear
wheel track ……………………………………….1.83 m
wheel base ………………………………………..1.285 m
main wheel diameter ……………………………0.35 m
nose wheel diameter …………………………… 0.3 m
