Easy Stitch - 5
Top Threading Instructions:
Please refer to diagram A and page 3 for machine parts.
1. Run the thread through the first
thread guide eye (15A) between
the top thread bobbin (6) and the
thread clamps (9).
2. The thread should be run between
the thread clamps (9) from the
top.
3. Run the thread through the
second thread guide eye (15B),
situated between the thread
clamps (9) and take up lever (12).
4. Run the thread through the eye on
the take up lever (12) and through
the third thread guide eye (15C).
5. Run the thread through the thread
guide eye (15D) attached to foot
holder pole spring (16).
6. Run thread through the needle
(20) from the left hand side to the
right hand side.
7. Place the thread under the
foot holder towards the back of
machine.
1
2
3
4
5
6
7
