JNGE Power Buck Series User Manual

JN-MPPT Buck series solar charge controller
address:no.99 yonghe road.Hefei.Anhui.China Tel：0551-65372576 http://www.hfjnge.com
- 4 -
 The controller running parameters can be viewed and set through the PC host
computer and mobile phone APP. For details, refer to the host computer and
APP manual (optional).
 With battery temperature compensation.
 It has comprehensive protection functions such as overcharge, over discharge,
over temperature, overload, reverse connection and so on.
3. product appearance
3.1 product appearance
pic 2-1: Product appearance dimension drawing
Table 2-1
：
Product weight and size
parameter name
Weight and Size
Model no.
JN-MPPT-MINI
JN-MPPT-AL
JN-MPPT-BL
JN-MPPT-CL
weight(kg)
1.25Kg
1.5kg
2.3kg
3.6kg
Size L*D*H(mm)
156*134*81mm
186*146*81mm
240*170*97mm
340*208*95mm
