JN-MPPT Buck type Solar Controller Product Manual
Address: No.99,Yonghe Road,High-Tech Zone,Hefei,Anhui ,China http://www.hfjnge.com
- 3 -
The second part: parameter configuration
1. the installation of the software
First put the CD that came with the controller into the CD-ROM drive of the computer, then read the
information on the CD-ROM and assemble the four installation programs in sequence.
2. the introduction of the software interface
After the software installation is complete, double-click the “Solar MPPT Controller Monitoring Software”
shortcut icon on the desktop of the computer to open the monitoring software operation interface.
Figure 2-1 Software interface diagram
Step
Program
Remarks
1
USB serial port driver
2
Microsoft Access database plugin
3
Installation Tip: This computer has
a newer version of the software
installed, no need to install it;
4
Solar MPPT Controller Monitoring
Software
