JN-MPPT Buck type Solar Controller Product Manual
Address: No.99,Yonghe Road,High-Tech Zone,Hefei,Anhui ,China http://www.hfjnge.com
- 5 -
3.2 System Settings:
Click the “System” menu in the menu bar to pop up the submenu. The submenu includes two menus
“Add Device” and “Language”. Click the “Add Device” submenu system to pop up the “Add Settings”
dialog box, as shown below figure2-3. As shown; click on the "Language" submenu to switch between
Chinese and English.as shown below figure2-4.
Figure 2-3 Add Device
Enter the device ID in the device ID field. (The device ID must be viewed on the JN-MPPT device first. It
cannot be set arbitrarily. The default value of the JN-MPPT is 6, edit the device name, and click the
“Add” button to complete. Device addition
Select a device in the device list, and display the parameters of the device in the device ID and device
name. If you want to modify it, modify it directly in the corresponding column, and then click the “Modify”
button to complete the modification of the device parameters.
Select a device in the device list and click the "Delete" button, then the device will be deleted.
Note: The device ID is the device identification address of JN-MPPT. Once the setting is completed,
please do not change it arbitrarily. Otherwise, the data connection will be abnormal.
Figure 2-4 Operation language settings
