- delicate warming for small amounts of food
- melng chocolate, buer, and foods that burn quickly.
-gentle simmering
- slow warming
INSTALLATION
SELECTION OF INSTALLATION EQUIPMENT
• Cut out the work surface according to the sizes shown in the drawing.
• For the purpose of installation and use, a minimum of 50mm space shall be preserved around
the hole.
• Be sure the thickness of the work surface is at least 30mm. please select heat-resistant work
surface material to avoid larger deformation caused by the heat radiation from the hotplate. As
shown below:
• Put a towel or cloth on the work surface. Place the hob face down on the protected surface.
• Apply the strip seal, supplied with the hop, which is for sealing it onto the work surface.
• Do not use silicone. Apply the seal to the edge of the bottom of the hob, leaving about 3mm from
the edge of glass. Apply the seal all around the circumference.
• Cut any excess and bring the two ends of the seal together so they match.
