59
Warning: The work surface material must use the impregnated wood or other insulation material.
Type
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
AI410
590
520
60
56
560
490
50
Under any circumstance, make sure the hob is well ventilated and the air inlet and outlet
are not blocked. Ensure the hob is in good work state. As shown below.
Note: The safety distance between the hotplate and the cupboard above the hotplate
should be at least 760mm.
