Joerns HML400 - Specifications; Base; Maximum Weight Capacity; Lift-Range of Boom

4
Joerns® Liing and Repositioning
Model HML400, C-HLA, C-HLA-2, C-HLA-2T
© 2015 Joerns Healthcare • IM-459001 RevC • 15-2003
Table of Contents
Important Precautions ............................................. 2
Specications ........................................................... 4
Assembly................................................................... 5
Inspection of Hydraulic Pump Stud ........................ 7
Operation ................................................................... 8
Leg Spreader Operation
Lifter Maintenance Checklist ................................. 10
Troubleshooting ..................................................... 11
Warranty .................................................................. 12
Specifications
Base
C-HLA ....................................................Adjustable U
C-HLA-2.................................................Adjustable U
C-HLA-2T ..............................................Adjustable U
HML400 .................................................Adjustable U
C-CB-L2.........................................................Fixed C
Maximum Weight Capacity
C-HLA ........................................................... 400 lbs.
C-HLA-2........................................................ 400 lbs.
C-HLA-2T ..................................................... 400 lbs.
HML400 ........................................................ 400 lbs.
C-CB-L2........................................................ 400 lbs.
Lift-Range of Boom
C-HLA .......................................................... 29" - 80"
C-HLA-2....................................................... 29" - 80"
C-HLA-2T .................................................... 34" - 84"
HML400 .................................................. 28.25" - 75"
C-CB-L2.............................................................45.5"
Width of Base
C-HLA ....................................................... 24" - 39.5"
C-HLA-2.................................................... 24" - 39.5"
C-HLA-2T ................................................. 24" - 39.5"
HML400 .................................................... 24" - 42.5"
C-CB-L2................................................................23"
Length of Base
C-HLA ...................................................................41"
C-HLA-2................................................................41"
C-HLA-2T .............................................................41"
HML400 ................................................................43"
C-CB-L2................................................................39"
Base Clearance
C-HLA ..................................................................5.5"
C-HLA-2...............................................................5.5"
C-HLA-2T ............................................................5.5"
HML400 .............................................................5.25"
C-CB-L2...............................................................4.5"
Finish
C-HLA ........................................................... Chrome
C-HLA-2........................................................ Chrome
C-HLA-2T ..................................................... Chrome
HML400 ............................................................... Ta n
C-CB-L2........................................................ Chrome
