TAOS Serie
MNP143ENV05 Date: 2018/02/21 Rev. 02 6 of 12
1. Symbols
2. Operating conditions
This machine is specially intended for indoor use. The machine leaves the factory adjusted to work properly at an
ambient temperature between 5 °C and 32 °C (41 °F and 89.6 °F) with a maximum humidity of 60%.
3. Dimensions and weights
Model
State
Height (mm /
“)
Width (mm / “)
Depth (mm / “)
Weight (kg / lb)
BASIC
Unpacked
1825 / 71,85
248 / 9,76
936 / 36,85
103 / 227,07
Packed
1895 / 74,6
318 / 12,51
1006 / 39,6
110,25 / 243,05
BASIC + MACHINE
Unpacked
1828 / 71,96
1047 / 41,22
981,5 / 38,64
407 / 897,28
Packed
1898 / 74,72
1117 / 43,97
1051,5 / 41,39
414,25 / 913,26
SLIM
Unpacked
1825 / 71,85
171,5 / 6,75
936 / 36,85
94,8 / 209
Packed
1895 / 74,6
241,5 / 9,5
1006 / 39,6
101,64 / 224,07
SLIM + MACHINE
Unpacked
1828 / 71,96
970,5 / 38,2
981,5 / 38,64
400,8 / 883,81
Packed
1898 / 74,72
1040,5 / 40,96
1051,5 / 41,39
407,64 / 888,69
TOUCH 10”
Unpacked
1825 / 71,85
248 / 9,76
936 / 36,85
105,6 / 232,8
Packed
1895 / 74,6
318 / 12,51
1006 / 39,6
112,98 / 249,07
TOUCH 10” + MACHINE
Unpacked
1828 / 71,96
1047 / 41,22
981,5 / 38,64
409,6 / 903,01
Packed
1898 / 74,72
1117 / 43,97
1051,5 / 41,39
416,98 / 919,28
4. Available heights
According to the American regulation, the heights of the front and the box of returning coins, have to be
delimited in an interval, which is defined by 2 limits or heights; low ADA and top ADA. In the European
 This symbol means there are more detailed explanations on this subject elsewhere in
the manual.
 This symbol means that the text in question refers to programming.
 This symbol indicates very important information.
 This symbol is a warning of high voltage hazard.
This symbol indicates that a given material should not be disposed of as domestic
waste.
This symbol indicates that a given material is recyclable.
This symbol indicates that Jofemar is committed to the environment.
