118
i-1
Installation


The drawing show the minimum safety requirements:
Figure i.1
The drawing has two sets of dimensions:
1 from the wall to the center of the holes: on
the left and top of the drawing
2 from the wall to the outline of the cabinet: on
the right and bottom of the drawing

The oor should be:
- horizontal; +/- 1° tolerance
- even; within 2 mm
- able to bear the weight of the balancer as stated in
Chapter 2 of the Operators Manual.
The oor on which the balancer will be installed
should not relay vibrations from other devices or
from outside the building. External vibrations may
affect the accuracy of the unit.
Note:
The balancer must be positioned directly
on the oor. Do not use spacers to ll gaps.
If the above conditions are satised, the balancer
does not need xing to the oor.

Refer to Chapter 2 of the Operators Manual for mains
power requirements.

MAINS OUTLET IS AVAILABLE.

OVER THE FLOOR, UNLESS PROTECTED BY
AN APPROVED COVER.
