Fig. 5-36 Minimization “Un.4”
(First measuring run of tire/rim assembly)
Readjust the wheel such that the valve is exactly
perpendicular to and above the main shaft.
Enter the valve position by pressing menu key
F1.
The Minimization “Un.5” screen (Fig. 5-37) is
displayed.
Fig. 5-37 Minimization “Un.5”
START is signalled on the screen.
Press the START key.
A measuring run is performed.
Next proceed as for optimization, starting at the
screen 5.10.5.
