Ordering information and accessories
The following tables provide the product code number and description for the CGM models and accessories.
Table 11: CGM Series ordering information
Product code number Description
M4-CGM04060-0
10-point General Purpose Application MS/TP Controller
Includes: MS/TP (and N2) communication; 10 points (3 UI, 1 BI, 4 CO, 2 BO); real-time clock; 24VAC input
M4-CGM09090-0
18-point General Purpose Application MS/TP Controller
Includes: MS/TP (and N2) communication; 18 points (7 UI, 2 BI, 4 CO, 2 AO, 3 BO); real-time clock; 24VAC
input
Table 12: CGM Controller accessories (order separately)
Product Code Number Description
IOM Series Expansion Modules
Refer to the Metasys System Field Equipment Controllers and Related Products
Product Bulletin (LIT-12011042) for a complete list of available IOM series
expansion modules
TL-CCT-0
License enabling Metasys Controller Configuration Tool (CCT) software for one
user
MS-FCP-0
License enabling Metasys Equipment Controller Firmware Package Files required
for CCT
Mobile Access Portal (MAP) Gateway
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
MS-DIS1710-0 Local Controller Display
NS Series Network Sensors
Refer to the NS Series Network Sensors Product Bulletin (LIT-12011574) for specific
sensor model descriptions.
AS-CBLTSTAT-0 Cable adapter for connection to 8-pin TE-6700 Series sensors
NS-WALLPLATE-0 Network Sensor Wall Plate
WRZ Series Wireless Room Sensors
Refer to the WRZ Series Wireless Room Sensors Product Bulletin (LIT-12000653) for
specific sensor model descriptions.
WRZ-7860-0
Refer to the WRZ-7860 Receiver for One-to-One Wireless Room Sensing Product
Bulletin (LIT-12011640) for a list of available products.
WRZ-SST-120
Wireless System Survey Tool (for use with the lower power 10mW WRZ and
WRZ-7860 systems)
Refer to the WRZ-SST-120 Wireless Sensing System Tool Installation Instructions
(LIT-24-10563-55) for usage instructions.
ZFR-HPSST-0
Wireless System Survey Tool (for use with the higher power WRG1830/ZFR183x
systems)
WRG1830/ZFR183x Pro Wireless Field Bus System
This system is used for installations that support BACnet/IP but can also coexist
with the ZFR1800 Series when installed under the same supervisor such as the
network engine.
Refer to the WRG1830/ZFR183x Pro Series Wireless Field Bus System Catalog Page
(LIT-1901026) for a list of available products.
Y64T15-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 92 VA, Foot Mount,
72.2 cm (30 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65A13-0
Transformer, 120 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount (Y65AS),
20.32 cm (8 in.), Primary Leads and 76.2 cm (30 in.) Secondary Leads, Class 2
Y65T31-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount
(Y65AR+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
Y65T42-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Hub Mount
(Y65SP+), 20.32 cm (8 in.), Primary Leads and Secondary Screw Terminals, Class 2
ACC-TBKINOUT-0
Input and Output terminal block replacement kit for SNC, CGM, CVM and XPM
products. Kit includes 5 of each 2, 3, and 4 position Input and Output terminal
blocks.
M4-CGM General Purpose Application Controller Installation Guide20
