898150-UIM-B-0113
Johnson Controls Unitary Products 7
FIGURE 5: Typical System Components
E
G
H
TAPE
REFRIGERANT LINE SET, CONDENSATE LINE
AND INDOOR / OUTDOOR CABLE
RETURN AIR
B
C
D
K
SUPPLY AIR
A
D
DISPLAY
INDICATORS
COOL
DRY
FAN
HEAT
RUN
TEMPERATURE SETTING
INDOOR AMBIENT TEMPERATURE
OR ERROR CODE
NOTE:
Temperature can be
displayed in either fahrenheit or celsius.
F
IMPORTANT:
The refrigerant metering device for this
system is located in the outdoor unit.
This makes it necessary to insulate the
refrigerant lines individually to prevent
sweating.
UTILITY
BUNDLE
WIRELESS
REMOTE
CONTROL
A. Remote control
B. Front anel
C. Filters
D. Guide louver with display
E. Line set (wrapped in foam insulation)
F. UV-rated tape (field-provided)
G. Wiring (field-provided)
H. Condensate drain line (field-provided) (wrapped in foam
insulation). Recommend installation of a vent when making long
INDOOR
UNIT
18 KBTU OUTDOOR UNIT
(ONE TO TWO ZONES)
24 KBTU OUTDOOR UNIT
(TWO TO THREE ZONES)
30 KBTU OUTDOOR UNIT
(TWO TO FOUR ZONES)
42 KBTU OUTDOOR UNIT
(TWO TO FIVE ZONES)
