E-Link Gateway Installation Instructions 9
Table 8: Equipment Quick Start Selections
APP Group Switch A Equipment Profile Quick Starts
Switch Settings 32168421Functionality
1
1
0 0 0 0 0 1 YK with SSS Imperial (YORK Talk-III) J version points
2 0 0 0 0 1 0 YK with VSD Imperial (YORK Talk-III) J version points
3
1
0 0 0 0 1 1 YT with SSS Imperial (YORK Talk-III) J version points
4 0 0 0 1 0 0 YT with VSD Imperial (YORK Talk-III) J version points
5
1
0 0 0 1 0 1 YS / YR with SSS Imperial (YORK Talk-III) J version points
6
1
0 0 0 1 1 0 YK with SSS Metric (YORK Talk-III) J version points
7 0 0 0 1 1 1 YK with VSD Metric (YORK Talk-III) J version points
8
1
0 0 1 0 0 0 YT with SSS Metric (YORK Talk-III) J version points
9 0 0 1 0 0 1 YT with VSD Metric (YORK Talk-III) J version points
10
1
0 0 1 0 1 0 YS / YR with SSS Metric (YORK Talk-III) J version points
11 0 0 1 0 1 1 YORK Talk II, 1200, 1 Section (YORK Talk-II) J version points
12 0 0 1 1 0 0 YORK Talk II, 4800, 1 Section (YORK Talk-II) J version points
13
2
0 0 1 1 0 1 YORK Talk II, 4800, 2 Sections (YORK Talk-II) J version points
14 0 0 1 1 1 0 YD Imperial (YORK Talk-III) J version points
15 0 0 1 1 1 1 YD Metric (YORK Talk-III) J version points
16 0 1 0 0 0 0 ECO2 / YPAL / S100 (BACnet MS/TP via an IPU-I)
17 0 1 0 0 0 1 YK with SSS Imperial (YORK Talk-III) K version points
18 0 1 0 0 1 0 YK with VSD Imperial (YORK Talk-III) K version points
19 0 1 0 0 1 1 YT with SSS Imperial (YORK Talk-III) K version points
20 0 1 0 1 0 0 YT with VSD Imperial (YORK Talk-III) K version points
21 0 1 0 1 0 1 YS / YR with SSS Imperial (YORK Talk-III) K version points
22 0 1 0 1 1 0 YK with SSS Metric (YORK Talk-III) K version points
23 0 1 0 1 1 1 YK with VSD Metric (YORK Talk-III) K version points
24 0 1 1 0 0 0 YT with SSS Metric (YORK Talk-III) K version points
25 0 1 1 0 0 1 YT with VSD Metric (YORK Talk-III) K version points
26 0 1 1 0 1 0 YS / YR with SSS Metric (YORK Talk-III) K version points
27 0 1 1 0 1 1 YST Imperial (YORK Talk-III) K version points
28 0 1 1 1 0 0 YIA Imperial (YORK Talk-III) K version points
29 0 1 1 1 0 1 YST Metric (YORK Talk-III) K version points
30 0 1 1 1 1 0 YIA Metric (YORK Talk-III) K version points
31 0 1 1 1 1 1 YEWS-D1/YEAS/YGAS (Modbus native)
32 1 0 0 0 0 0 YD Imperial (YORK Talk-III) K version points
33 1 0 0 0 0 1 YD Metric (YORK Talk-III) K version points
34 1 0 0 0 1 0 YMC2 Imperial (YORK Talk-III) K version points
35 1 0 0 0 1 1 YMC2 Metric (YORK Talk-III) K version points
63 1 1 1 1 1 1 Reserved for Field adjustments
1. A Quick Start that references a Solid State Starter (SSS) is also applicable to a mechanical starter.
2. Two sections are required for equipment equipped with three or more compressors, or two systems.
