4 FX20/60 Supervisory Controllers Installation Instructions
Table 1: Accessory Module Details
Model Description Notes
LP-FXPM24-0
Power module for FX20/FX60
24 VAC/DC, DIN rail mountable
Install only one power module per FX20/FX60, regardless
of type.
LP-FXPM263-0
Power module for FX20/FX60
90-263 VAC, DIN rail mountable
Install only one power module per FX20/FX60, regardless
of type.
LP-FXNDIO16-0
16 channel input/output module for
FX20/FX60, DIN rail mountable
Provides the following I/O points:
 8 Universal Inputs (UIs)
 4 Digital Outputs (DOs), Single Poll Single Throw
(SPST) relay type
 4 Analog Outputs (AOs) (0-10 VDC)
Up to four (maximum) NDIO16 accessory modules are
supported.
LP-FXNDIO34-0
34 channel input/output module for
FX20/FX60, DIN rail mountable. In
addition, the NDIO34 provides power to
the attached FX20/FX60, using an
externally supplied 24 VAC transformer or
24 VDC power supply.
Provides the following I/O points:
 16 Universal Inputs (UIs)
 10 Digital Outputs (DOs), SPST relay type
 8 Analog Outputs (AOs) (0-10 VDC)
One NDIO34 plus up to 2 additional NDIO16 modules are
supported. Do not power the NDIO34 if using a separate
wall plug power module.
LP-FXRIO16-0
16 channel remote input/output Provides the following I/O points:
 8 Universal Inputs (UIs)
 4 Form A Relay Outputs
 4 1-10 VDC Analog Outputs
 Up to 4 FXRIO10 modules supported on FX20
 Up to 16 FXRIO16 modules supported on FX60
