Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
Pre Start-Up Checklist
Date: ______________ Customer: ____________________________________ Phone No: ___________________
Job Name: ______________________________________ Job Address: _______________________________________
Order No.: ______________________________________ City: _______________________________________
Contract No.: ____________________________________ State: ______________ Zip Code: _____________
Serial No.: ______________________________________ Country: _______________________________________
Model No.: ___________________________________________________________________________________________
Installation Completion Date: ________________________ Requested Start-Up Date: _____________________________
NOTE: Check off each item as required. Cross out (x) items that do not apply.
General Inspection Completed See Notes
1. Unit inspected for shipping, storage, or rigging damage ............................................................
2. Unit installed with proper clearances..........................................................................................
3. Unit installed with slope limitations .............................................................................................
4. Ductwork is completed and cleared of all obstructions ..............................................................
5. All eld wiring (power and control) is complete (matching the nameplate) ................................
6. The building automation system (BAS) is connected to the unit and operational (if applicable)
7. Variable air volume (VAV) units:
a. The VAV boxes are verified as operational ................................................................................
b. Discharge air static pressure transducer tubing is installed in the appropriate location ........
8. Single zone VAV (SZVAV) units (check whichever option is applicable):
a. A NetSensor is connected to the SA bus on the main control board ....................................
b. The BAS is communicating a zone temperature to the unit ..................................................
9. Exhaust/return fan units:
a. Building static pressure transducer tubing is installed in the appropriate location ...................
10. When either of the discharge air static or building static pressure transducers are installed, an
outdoor pressure reference is also eld installed via the shipped loose kit ..................................
11. Condensate drain is installed and trapped properly ...................................................................
12. Gas heat units:
a. The gas line is installed per local codes and purged of air ...................................................
b. The incoming gas pressure is within the range specified on the unit nameplate ..................
13. Hot water/steam units:
a. Field piping to the hot water/steam coil is completed ..............................................................
b. The shipped loose modulating valve is installed and field wiring to the valve is completed .....
25–50 Tons
Johnson Controls
®
Premier Rooftop Units
R-410A
In an effort to provide the highest level of service, the following checklist is provided to ensure that all necessary installation
items are completed prior to a scheduled supervised start-up for the rooftop unit. Refer to the appropriate Installation and Main-
tenance Manual (Form 5586959-JIM) before evaluating the information on this Checklist. E-mail the completed checklist to
cg-upgtechsupport@jci.com.
7
