Johnson Controls GVC Series User Manual

Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
99
Operation
BACnet
Attributes
Object
Type
Object
ID
Read/
Write
Short Description
Long
Description
Point Denitions (Units)
NetOAH AV 29546 R/W NetOAH
Network Override
Outdoor Air
Humidity
A BAS command to override outside
air humidity (0–100 %RH)
OprOAQ AV 29547 R OprOAQ
Operational
Outdoor Air
Quality
Displays the active outdoor air CO
2
(PPM)
NetOAQ AV 29549 R/W NetOAQ
Network Override
Outdoor Air
Quality
A BAS command to override outdoor
air CO
2
(PPM)
FanVFD AV 29551 R SF-O Fan % Command
Displays the output from the control
to the supply fan VFD (%)
Fan-RT AV 29554 R SF-Runtime
Supply Fan
Accumulated
Runtime
Displays the supply fan runtime
(hours)
FanOffDlyCool AV 29559 R/W FanOffDlyCool
Fan Off Delay for
Cool
A BAS command to adjust the supply
fan runtime after cooling is turned
OFF (0–255 seconds)
FanOffDlyHeat AV 29561 R/W FanOffDlyHeat
Fan Off Delay for
Heat
A BAS command to adjust the supply
fan runtime after heating is turned
OFF (0–30 seconds)
DAT AV 29564 R DAT DAT Displays the active DAT (°F)
DctPrs AV 29565 R DA-P
Discharge Air
Static Pressure
Displays the active discharge air
static pressure (iwg)
DctPrs-Sp AV 29566 R/W DctPrs-Sp
Duct Pressure
Setpoint
A BAS command to adjust active
duct static pressure setpoint (iwg)
DctShutdownSp AV 29567 R/W DctShutdownSp
Duct Pressure
Shutdown
Setpoint
A BAS command to adjust the
duct static pressure unit shutdown
setpoint (iwg.)
#ClgStgs AV 29576 R #ClgStgs
Number of
Cooling Stages
Installed
Displays the number of cooling
stages installed.
MinRtCoolStg AV 29578 R MinRtCoolStg
Minimum Runtime
for a Cooling
Stage
Displays the minimum runtime for a
cooling stage (3–10 minutes)
Circ1ClgOATCutout AV 29581 R/W Circ1ClgOATCutout
Circuit 1 OAT
Cooling Cutout
Circuit 1 compressors are disabled
when OAT drops below this setpoint
(...75.0°F)
Circ2ClgOATCutout AV 29582 R/W Circ2ClgOATCutout
Circuit 2 OAT
Cooling Cutout
Circuit 2 compressors are disabled
when OAT drops below this setpoint
(...75.0°F)
Freeze-Sp AV 29592 R/W Freeze-Sp
Freeze Condition
Setpoint
A BAS command to disable cooling
to prevent cooling coil from freezing
(20.0–32.0°F)
ClgDATUp-SP AV 29604 R/W ClgDATUp-SP
Cooling DAT
Upper Setpoint
The upper setpoint for the DAT reset
schedule (41.0–80.0°F)
ClgDATLo-SP AV 29605 R/W ClgDATLo-SP
Cooling DAT
Lower Setpoint
The lower setpoint for the DAT reset
schedule (40.0–79.0°F)
OprClgDAT-SP AV 29607 R OprClgDAT-SP
Operating Cooling
DAT Setpoint
Displays the active DAT setpoint (°F)
Table 32: BACnet Points List (Continued)
