SPECIFICATIONS - NORTH AMERICA
Items
Parameters
IQ4 Hub
LED Indicator
Status LED
Green (Disarmed), Red (Armed), Triple full color RGB LED
Speaker/Siren
4w x 1
Front Facing 4watt x1 speaker and 85dB siren
Microphone
MEMs x 1
1 MEMs (micro electro mechanical system) Microphone
Tamper
Tamper Switch
Dual Panel and wall tamper switch with spring release
Battery
Type 18650
Lithium Ion 3000mAh. Ningbo Veken Battery Co., Ltd, Model VT27 or Icon Energy System Co. Ltd,
Model IAN034NA
Buttons
Hard Button
Single wake/sleep button used for sleep/wake, hard reboot, and clean screen cancel
Mechanical
Dimension
6.1”H x 7.5”W x 1”D (155mm x 191mm x 26mm)
Power Supply
AC/DC External Plug-in
Adapter
Output: 7vDC (⎓) 1000mA CC, or 7vDC(⎓) 1.5A CC, Input 100-240VAC 50/60Hz. Adapter evaluated at
120vAC for UL/cUL
Mount
Back Plate
SmartMount wall mount included. SmartMount table stand sold separately.
Certification
UL/ULC
UL/ULC Residential Fire and Burglary and UL/ULC Commercial Burglary Alarm Control Unit. Compliant
with standards: UL985, UL1023, UL2610, ULC-S545, ULC-S304
FCC
2AAJXQS-IQ4H (may contain additional modules with separate FCC ID’s)
IC
11205A-QSIQ4H (may contain additional modules with separate IC ID’s)
NOM, IFETEL
Certificado No.: Reserved
Temperature
Operational
0 to 49C, up to 93% relative humidity, indoor, dry ordinary locations use only
Storage
-20 to 50C
