PANEL OVERVIEW
EXTERIOR BACK
For EN Grade 2
applications, these
mounting holes
shall be used
Single, double or
triple gang box
compatible
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 6 198
Locking Screw w/
Retention Spring
For UL2610 and EN Grade
2 applications this screw
shall be used for tamper
protection against
mounting removal
