SPECIFICATIONS - EUROPE & UNITED KINGDOM
Items
Parameters
IQ4 Hub
Microphone
MEMs x 1
1 MEMs (micro electro mechanical system) Microphone
Tamper
Tamper Switch
Dual Panel and wall tamper switch with spring release
Battery
Type 18650
Lithium Ion 3.7v/3Ah. Ningbo Veken Battery Co., Ltd, Model VT27 or Icon Energy System Co. Ltd, Model
IAN034NA. Low battery threshold: 3.6v and 10% indication for battery capacity
Buttons
Hard Button
Single wake/sleep button used for sleep/wake, hard reboot, and clean screen cancel
Mechanical
Dimension
6.1”H x 7.5”W x 1”D (155mm x 191mm x 26mm)
Weight
Approximately 1.3 kg
Power Supply
AC/DC External Plug-in
Adapter
Output: 7vDC (⎓) 1500mA CC, Input 230 VAC -10%/+15%, 0.68A, 50Hz (for CE/EN Certified Systems).
Current consumption during set & unset procedure: 70mA; quiescent current: 285 mA; max current in
alarm mode: 1070 mA. Control Panel and power supply are suitable for installation only within the
protected premises.
Standyby Time
24h (Battery recharge time [up to 80% of capacity]: 12 h. Energy level of battery in its charged state is
100 %).
Mount
Back Plate
SmartMount wall mount included. SmartMount table stand sold separately. For EN 50131 systems only
wall mount is allowed.
Certification
Europe
CE & CertAlarm (EN Grade 2): Pending; Denmark: FP -- Reserved;!
Finland: FFFH:-- Reserved; Norway: FG – Reserved; Sweden: SBSC -- Reserved
Great Britain
UKCA: Pending. PD 6662 & BS 8243: Pending
Environment
Altitude: Min 0 m to Max 2000m!
Humidity range: 20% RH to 93% RH (non-condensing)!
Operating Ambient Temperature: Min -10°C to Max 40°C !
Storage Ambient Temperature: in -20°C to Max 55°C !
EN50130-5 Class I - Indoor ordinary location
