Johnson Controls J ZH Series User Manual

5566217-JIM-C-1019
Johnson Controls Ducted Systems 31
Condenser fan data
Quantity of fans 2 2 2 2 4
Fan diameter (inches) 24 24 24 24 24
Type Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct
Quantity of motors 2 2 2 2 4
Motor HP each 1/3 3/4 3/4 3/4 1/3
No. of speeds 1 1 1 1 1
RPM 850 1110 1110 1110 850
Total CFM 6700 8600 9400 9400 14000
Belt drive evap. fan data
Quantity 1 1 1 1 1
Fan size (inches) 12 x 12 12 x 12 15 x 15 15 x 15 15 x 15
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor sheave 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VP56
Blower sheave AK74 AK64 AK74 AK61 AK94 AK74 AK84 AK74 AK74 BK77
Belt A49 A49 A49 A49 A56 A54 A56 A54 A54 BX55
Motor HP each 1-1/221-1/23232335
RPM 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56 56 56 56 184T
Filters
Quantity - size
4 - (24 x 16 x 2)
6,7
4 - (24 x 16 x 2)
6,7
4 - (24 x 20 x 2)
6,7
4 - (24 x 20 x 2)
6,7
4 - (24 x 20 x 2)
6,7
4 - (24 x 16 x 4)
8
4 - (24 x 16 x 4)
8
4 - (24 x 20 x 4)
8
4 - (24 x 20 x 4)
8
4 - (24 x 20 x 4)
8
1. Cooling only unit or cooling unit with electric heat
2. Cooling unit with gas heat
3. Does not meet DOE 2018 minimum efficiency requirements
4. First stage 60% of full capacity
5. All J**ZH units have crankcase heaters standard
6. 2 in. throwaway, standard, MERV (Minimum Efficiency Reporting Value) 3
7. 2 in. pleated, optional, MERV 8
8. 4 in. pleated, optional, MERV 13
Table 11: J06 through 12ZH physical data (continued)
Component
Models
J06ZH J07ZH J08ZH J10ZH J12ZH
Nominal tonnage 6.5 7.5 8.5 10 12.5
