Johnson Controls JHET Series User Manual

6112628-UIM-B-0622
14 Johnson Controls Ducted Systems
C36D
8HK(0,1)6500206 10 15.6 16.7 20 20
8HK(0,1)6500506 20 26.4 28.7 30 30
8HK(0,1)6500806 32 39.6 43.3 40 45
8HK(0,1)6501006 40 48.0 52.6 50 60
8HK(1,2)6501506 60 69.7 76.5 70 80
8HK(1,2)6502006 80 91.3 100.4 100 110
C42F
8HK(0,1)6500206 10 15.6 16.7 20 20
8HK(0,1)6500506 20 26.4 28.7 30 30
8HK(0,1)6500806 32 39.6 43.3 40 45
8HK(0,1)6501006 40 48.0 52.6 50 60
8HK(1,2)6501506 60 69.7 76.5 70 80
8HK(1,2)6502006 80 91.3 100.4 100 110
C48G
8HK(0,1)6500206 10 17.6 18.7 20 20
8HK(0,1)6500506 20 28.4 30.7 30 35
8HK(0,1)6500806 32 41.6 45.3 45 50
8HK(0,1)6501006 40 50.0 54.6 60 60
8HK(1,2)6501506 60 71.7 78.5 80 80
8HK(1,2)6502006 80 93.3 102.4 100 110
D48G
8HK(0,1)6500206 10 17.6 18.7 20 20
8HK(0,1)6500506 20 28.4 30.7 30 35
8HK(0,1)6500806 32 41.6 45.3 45 50
8HK(0,1)6501006 40 50.0 54.6 60 60
8HK(1,2)6501506 60 71.7 78.5 80 80
8HK(1,2)6502006 80 93.3 102.4 100 110
C60H
8HK(0,1)6500206 10 17.6 18.7 20 20
8HK(0,1)6500506 20 28.4 30.7 30 35
8HK(0,1)6500806 32 41.6 45.3 45 50
8HK(0,1)6501006 40 50.0 54.6 60 60
8HK(1,2)6501506 60 71.7 78.5 80 80
8HK(1,2)6502006 80 93.3 102.4 100 110
D60H
8HK(0,1)6500206 10 17.6 18.7 20 20
8HK(0,1)6500506 20 28.4 30.7 30 35
8HK(0,1)6500806 32 41.6 45.3 45 50
8HK(0,1)6501006 40 50.0 54.6 60 60
8HK(1,2)6501506 60 71.7 78.5 80 80
8HK(1,2)6502006 80 93.3 102.4 100 110
8HK(1,2)6502506 100 114.9 126.3 125 150
D60J
8HK(0,1)6500206 10 17.6 18.7 20 20
8HK(0,1)6500506 20 28.4 30.7 30 35
8HK(0,1)6500806 32 41.6 45.3 45 50
8HK(0,1)6501006 40 50.0 54.6 60 60
8HK(1,2)6501506 60 71.7 78.5 80 80
8HK(1,2)6502006 80 93.3 102.4 100 110
8HK(1,2)6502506 100 114.9 126.3 125 150
1. (0,1) - 0 = no service disconnect or 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar or 2 = with service disconnect and breaker jumper bar.
3. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. Refer to the latest edition of the National Electric Code or in
Canada the Canadian electrical Code and local codes to determine correct wire sizing.
Table 9: Electrical data for single source power supply: 208/230-1-60 (continued)
Air handler models
Heater models
1,2
Heater
amps (A)
at 240 V
Field wiring
Minimum circuit ampacity (A)
MOP
3
(A)
208 V 230 V 208 V 230 V
