6112628-UIM-B-0622
18 Johnson Controls Ducted Systems
Notes:
1. No electric heat installed
2. Air handler units are tested to UL60335-2-40 standards up to 0.6 in. W.C. external static pressure.
3. Dry coil conditions only; tested without filters
4. For optimal performance, external static pressures of 0.2 in. W.C. to 0.5 in. W.C. are recommended. Heating applications are tested at 0.5 in. W.C. external static
pressure.
5. Airflow data shown is from testing performed at 230 V. JHET units use a standard ECM constant torque motor and there is minimal variation of airflow at other distri-
bution voltage values. The above data can be used for airflow at other distribution voltages.
C48G
High (5)
CFM 1925 1900 1875 1850 1800 1775 1750 1725 1700 1675
W 588 604 619 635 650 666 681 697 712 728
Medium high (4)
CFM 1750 1700 1675 1650 1600 1575 1550 1500 1475 1450
W 435 449 463 476 490 504 517 531 545 558
Medium (3)
CFM 1400 1350 1300 1275 1225 1175 1125 1075 1050 1000
W 235 245 256 266 277 287 298 308 319 329
Medium low (2)
(2)
CFM 1200 1150 1100 1050 1000 925 875 825 775 725
W 157 166 176 185 194 203 212 221 230 239
Low (1)
CFM 925 875 800 750 700 625 575 500 450 375
W 93 100 107 114 121 128 135 142 149 156
D48G
High (5)
CFM 2050 2000 1975 1950 1900 1875 1850 1800 1775 1750
W 579 597 615 632 650 668 686 704 722 739
Medium high (4)
CFM 1850 1800 1775 1725 1700 1650 1625 1575 1550 1500
W 431 446 461 476 492 507 522 537 552 568
Medium (3)
CFM 1625 1600 1550 1500 1450 1425 1375 1325 1275 1250
W 305 318 332 345 358 371 384 397 410 423
Medium low (2)
CFM 1275 1200 1150 1100 1050 975 925 875 825 750
W 159 169 179 189 199 208 218 228 238 248
Low (1)
CFM 1000 925 875 800 750 675 600 550 475 400
W 96 103 111 118 126 133 141 148 156 163
C60H
High (5)
CFM 1925 1900 1875 1850 1825 1775 1750 1725 1700 1675
W 564 578 593 608 623 638 653 668 683 698
Medium high (4)
CFM 1750 1725 1675 1650 1625 1575 1550 1525 1475 1450
W 420 433 447 461 474 488 502 515 529 543
Medium (3)
CFM 1375 1350 1300 1250 1225 1175 1125 1100 1050 1000
W 222 233 244 255 266 277 288 299 310 321
Medium low (2)
CFM 1200 1150 1100 1050 1000 950 900 850 800 750
W 154 163 173 182 192 201 211 220 229 239
Low (1)
CFM 950 900 825 775 725 650 600 550 475 425
W 91 98 105 113 120 127 134 142 149 156
D60H
High (5)
CFM 1925 1900 1875 1825 1800 1775 1750 1700 1675 1650
W 500 515 530 545 560 575 590 605 620 635
Medium high (4)
CFM 1775 1750 1725 1675 1650 1600 1575 1525 1500 1450
W 393 407 421 435 449 463 477 491 504 518
Medium (3)
CFM 1450 1400 1325 1275 1225 1175 1125 1075 1025 975
W 212 223 235 246 258 269 281 292 304 315
Medium low (2)
CFM 1225 1175 1125 1050 1000 950 875 825 775 700
W 146 156 166 176 185 195 205 215 225 235
Low (1)
CFM 975 900 850 775 700 625 550 475 425 —
W 87 95 102 110 118 125 133 141 148 —
D60J
High (5)
CFM 2100 2075 2050 2025 2000 1975 1925 1900 1875 1850
W 691 707 724 740 757 773 790 806 823 839
Medium high (4)
CFM 1925 1900 1875 1825 1800 1775 1725 1700 1675 1650
W 516 533 550 566 583 600 617 633 650 667
Medium (3)
CFM 1750 1725 1675 1650 1600 1575 1525 1500 1450 1425
W 394 409 423 437 452 466 480 495 509 524
Medium low (2)
CFM 1350 1275 1225 1175 1125 1075 1025 975 925 875
W 188 199 210 221 232 242 253 264 275 286
Low (1)
CFM 1200 1150 1100 1025 975 925 850 800 750 675
W 145 155 165 174 184 193 203 212 222 232
Table 13: Airflow data (CFM per Watts) (continued)
Models
Blower
motor speed
External static pressure (in. W.C.)
Unit 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
