LX Series Free Programmable LX-PRGxxx-11 Controllers Installation Instructions18
Outputs Digital (Triac) Outputs: 5
Universal Outputs: 3
Digital:
24 VAC Triac, digital (on/off), floating, or PWM; software configurable
0.5 A continuous
1.0 A at 15% duty cycle for a 10-minute period
PWM control: adjustable period from 2 seconds to 65 seconds
Floating control: requires two consecutive outputs
minimum plus on/off: 500 milliseconds
adjustable drive time period
External power supply
Universal:
Linear (0-10 VDC)
Digital (on/off), PWM, or floating (0 to 12 VDC); software configurable; built-in snubbing
diode to protect against back EMF (for example when used with a 12 VDC relay).
PWM control: adjustable period from 2 seconds to 65 seconds
Floating control:
minimum plus on/off: 500 ms
adjustable drive time period
60 mA maximum at 12 VDC (60
°C [140°F])
minimum resistance 200 ohms
Auto reset fuse
60 mA at 60
°C (140°F)
100 mA at 20
°C (68°F)
Output Resolution: 10-bit digital/analog converter
Electromagnetic Compatibility CE Emission: EN61000-6-3: 2007 Generic standards for residential, commercial, and
light-industrial environments (pending).
CE Immunity: EN61000-6-1: 2007; Generic standards for residential, commercial, and
light-industrial environments (pending).
FCC: This device complies with FCC rules part 15, subpart B, class B (pending)
LN Series Communicating
Sensor
Communication: RS-485
Number of sensors per controller: up to 4, in daisy-chain configuration
Cable: Cat 5e, 8 conductor twisted pair
Connector: RJ-45
Agency Compliance United States:
Under UL 916, Energy Management Equipment
Material
1
: UL94-5VA
Canada:
Under UL 916, Energy Management Equipment
Material
1
: UL94-5VA
Europe: CE Mark – Johnson Controls, Inc., declares that the products are in compliance
with the essential requirements and other relevant provisions of the EMC Directive
2004/108/EC.
1. All materials and manufacturing processes comply with the RoHS directive and are marked according to the Waste
Electrical and Electronic Equipment (WEEE) directive.
LX-PRG203-11 (Part 1 of 2)
