Technical Specifications
Table 6: MAP Gateway
TL-MAP1810-0Px: Portable MAP Gateway (Includes MAP Gateway, RJ-12 cable, bumper guard, and
lanyard.) US-compatible countries.
TL-MAP1810-0Sx: Stationary MAP Gateway (Includes MAP Gateway, field bus adapter, mounting
bracket, and 100 to 240 VAC power supply.) US-compatible countries.
Product Code
1
From SA/FC bus: 15 VDC at 2.7 VA maximumPower Consumption
Operating: 0 to 50°C (32 to 122°F)
Operating Survival: -30 to 60°C (-22 to 140°F)
Non-Operating: -40 to 70°C (-40 to 158°F)
Ambient Temperature
Conditions
Storage: -40 to 70°C (-40 to 158°F); 5 to 95% RH 30°C (86°F) maximum dew point conditions
Operating: 0 to 50°C (32 to 122°F); 5 to 95% RH, 30°C (86°F) maximum dew point conditions
Ambient Humidity
Conditions
Wireless Local Area Network (WLAN) Transmission Power:
+14.5 dBm, 54 Mbps
+12.5 dBm, 65 Mbps
Transmission Power
(Typical)
-76 dBm, 10% packet error rate (PER ), 54 Mbps
-73 dBm, 10% PER, 65 Mbps
WLAN Receiver
Sensitivity (Typical)
Wireless Communication:
2.4 GHz ISM bands, 802.11 b/g/n, 11/22/54 Mbps
Serial Communication (SA/FC Bus):
9600, 19.2k, 38.4k, or 115.2k bps
Ethernet Communication:
10, 100 Mbps
Transmission Speeds
Wireless Communication:
30 m (100 ft) line-of-sight indoors
91 m (300 ft) line-of-sight outdoors
WLAN Range Performance:
0 - 50 ft = Excellent
50 - 100 ft = Good
100 - 300 ft = Weakest, approaching out of range
Transmission Range
(Typical)
WPA2-PSK TKIP (Wi-Fi Protected Access Pre-Shared Key mode Temporal Key Integrity Protocol)
WPA2-EAP-PEAP
WPA2-EAP-TLS
Wireless Security
One SA/FC port (6-pin port; connects with 1.5 m [4.9 ft] RJ-12 field bus cable)
One USB port (Micro-B port; 2.0; supports Open Host Controller Interface [Open HCI] specification)
Network and Serial
Interfaces
Unit alone: 120 x 70 x 24.5 mm (4-23/32 x 2-3/4 x 31/32 in. when used vertically)
Unit in shell: 128 x 75 x 29.5 mm (5-1/32 x 2-61/64 x 1-5/32 in. when used vertically)
Dimensions
(H x W x D)
White Acrylonitrile butadiene styrene (ABS) bracketHousing
13Mobile Access Portal Gateway Installation Instructions
