Canada
Industry Canada Statement
The term IC before the certification/registration number
only signifies that the Industry Canada technical
specifications were met.
Le terme « IC » précédant le numéro
d'accréditation/inscription signifie simplement que le
produit est conforme aux spécifications techniques
d'Industry Canada.
Installation
Observe the following guidelines:
• Verify that all parts shipped with the MAP Gateway.
• Keep the unit encased in the protective shell. If not
protected by the enclosure in which it ships, the MAP
Gateway may be subject to physical damage.
Parts Included (Portable Model)
• MAP Gateway
• Protective shell
• 6-pin RJ-12 connector cable
• Lanyard
• Installation Instructions
•
Mobile Access Portal Gateway Quick Start Guide
(Part No. 24-10737-16)
Parts Included (Stationary Model)
• MAP Gateway
• Field bus adapter
• Mounting bracket (with locking screw)
• Installation Instructions
•
Mobile Access Portal Gateway Quick Start Guide
(Part No. 24-10737-16)
Special Tools Needed
To use the MAP Gateway, you need a mobile device
(tablet or smart phone) or computer (laptop or desktop)
that supports Wi-Fi.
If the unit is permanently mounted to a vertical surface
without a DIN rail, you need screws to mount the unit.
The specific screw types depend upon the surface to
which the unit is mounted. The screw holes on the MAP
Gateway can accommodate M3.5 and #6 screws.
Use of the mounting bracket locking screw requires a
T15 Torx driver.
Portable Use
When used as a portable unit, the MAP Gateway should
be housed in the supplied shell. During use, the unit can
be temporarily hung on nearby equipment using the
supplied lanyard.
Risk of Personal Injury. Do not wear or hold the MAP
Gateway during use, and only use or install the MAP
Gateway at locations where there is at least 20 cm
between the built-in antenna and all persons. Failure to
do so may result in minor or moderate personal injury.
MISE EN GARDE:
Risque de blessure. Ne pas porter ou soutenir l'MAP
Gateway durant son utilisation et utiliser ou installer
l'MAP Gateway uniquement à un emplacement offrant
une distance minimum de 20 cm entre l'antenne intégrée
et toute personne. Le non-respect de cette précaution
risque de provoquer des blessures légères ou de gravité
modérée.
Observe the following guidelines when using a portable
MAP Gateway:
• Do not use the RJ-12 cable to support the weight of
the MAP Gateway. Use the lanyard to support it.
• Keep the MAP Gateway in the protective shell with
which it ships. To insert the MAP Gateway into the
shell, stretch the shell edges and slide the MAP
Gateway unit into place (Figure 1). This shell protects
the unit from drops up to 1.22 m (4 ft).
• The MAP Gateway has not been designed for
prolonged outdoor use. Leaving it in outdoor
environments (such as inside rooftop units) may result
in damage.
• Objects (including ductwork, cabinets, doors, and
glass) can impede the wireless signal. Minimize the
number of objects between the connected computer
or mobile device and the MAP Gateway. Use line of
sight, if possible.
• Metal objects (such as cabinet doors, enclosures, and
pipes) and concrete objects (such as pillars, walls,
and ceilings) may limit Wi-Fi service. To
accommodate potential structural obstacles on site,
the MAP Gateway can be mounted flat or on the side.
