Johnson Controls P77 Series User Manual

P77
Issue 13/05/2003
© 2003 Johnson Controls Inc. Catalogue Section 6
Order No. PD-P77-E
5
Dimensions (mm)
53
88
23.5
61
22.5
80 5.5
10
10 8
55
16.525
970
48.525
13
1
2
4
3
5
6
6
26
21.5 1.5
53
1. lock plate (if applied)
2. two mounting holes Ø 4.5 mm (knock out)
3. four mounting holes Ø M4 (back side)
4. cable inlet grommet (cable range Ø 5 to Ø 13 mm)
5. power element:
Style 5:
7
/ 16 "-20 UNF male (shown)
Style 15:
1
/ 4 "-18 NPT female
6. reset button
Fig. 12
