Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
78/168
008831 en 2020.10
Physical and connection data
5.4 Connection data
5.4.1 Connections to compressor unit
See unit dimension sketches.
Screw compressor dimension
Fig. 57
Approx.
dimensions
SGC
1913
SGC
1918
SGC
2313
SGC
2317
SGC
2321
SGC
2813
SGC
2817
SGC
2821
SGC
2824
SAB
193 S
SAB
193 L
SAB
233 S
SAB
233 L
SAB
233 E
SAB
283 S
SAB
283 L
SAB
283 E
SAB
283 X
A
mm
(In.)
1445.3
(56.90)
1532.1
(60.32)
1655.6
(65.18)
1737.1
(68.39)
2000.6
(78.76)
1979.7
(77.94)
2078.8
(81.84)
2382.5
(93.80)
2500.9
(98.46)
B
mm
(In.)
698.5
(27.50)
712.2
(28.04)
726.4
(28.60)
757.7
(29.83)
759.2
(29.89)
881.6
(34.71)
900.7
(35.46)
1346.2
(35.53)
C
mm
(In.)
253.5
(9.98)
278.8
(10.98)
341.9
(13.46)
D
mm
(In.)
668.0
(26.30)
706.1
(27.80)
815.8
(32.12)
841.2
(33.12)
841.2
(33.12)
939.8
(37.00)
990.5
(39.00)
E
mm
(In.)
580.7
(22.86)
662.9
(26.10)
667.7
(26.29)
F
mm
(In.)
125.0
(4.92)
211.8
(8.34)
156.6
(6.52)
246.9
(9.72)
340.4
(13.40)
185.7
(7.31)
284.7
(11.21)
397.9
(15.67)
483.1
(19.02)
G
mm
(In.)
420.1
(16.54)
511.0
(20.12)
558.8
(22.0)
H
mm
(In.)
208.1
(8.19)
243.2
(9.58)
327.2
(12.88)
I
mm
(In.)
127.0
(5.00)
152.4
(6.00)
203.2
(8.00)
254.0
(10.00)
TOP VIEWSIDE VIEW
H
A
L
D
M
I (SUCT.)
GB
C
E
K
N
O
F
J (DISCH.)
