CCS Smart Equipment Control Board for Single Packaged Unit (SPU) Controller Installation Instructions8
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners. © 2015 Johnson Controls, Inc.
Building Efficiency
507 E. Michigan Street, Milwaukee, WI 53202
Technical Specifications
Unit Control Board with BACnet® Communication
Product Code Number SE-SPU1011-1 – Single-stage Unit Control Board with Field Bus Expansion Module
SE-SPU1012-1 – Dual-stage Unit Control Board with Field Bus Expansion Module
Power Supply Requirement 24 VAC (nominal, 20 VAC minimum/30 VAC maximum), 50/60 Hz, Power Supply
Class 2 (North America), Safety
Power Consumption 15 VA maximum
Note: VA ratings do not include any power supplied to the peripheral devices connected
to binary outputs (BOs)
Ambient Conditions Operating: -40 to 158°F (-40 to 70°C); 10 to 90% RH noncondensing
UI Operating: -4 to 158°F (-20 to 70°C); 10 to 90% RH noncondensing
Storage: -40 to 194°F (-40 to 85°C); 5 to 95% RH noncondensing
Processor RX631 Renesas® microcontroller
Memory 2 MB internal program flash, 32 KB internal E2Data flash, 4 MB external serial flash
memory
Input and Output Capabilities SE-SPU1011-1:
9 AIs: 7: 10k RTD, 1: 0 to 10 VDC, 1: 24 VAC Voltage Monitor
13 BIs: 24 VAC input with contact cleaning circuits
5 BOs: 4: relay outputs, 1: Transistor output
SE-SPU1012-1:
12 AIs: 9: 10k RTD, 2: 0 to 10 VDC, 1: 24 VAC Voltage Monitor
1 AOs: 2 to 10 VDC, 10 mA maximum
16 BIs: 24 VAC input with contact cleaning circuits
8 BOs: 7: relay outputs, 1: transistor output
Housing Unpackaged printed circuit board (PCB) with silkscreen labels
Mounting Mounted with Nylon Standoffs
Dimensions
(Height x Width x Depth)
1.44 x 6.5 x 5.27 in. (36 x 165 x 133 mm)
Shipping Weight SE-SPU1011-1 – 3.6 lb (1.63 kg)
SE-SPU1012-1 – 3.7 lb (1.68 kg)
Compliance United States:
UL Recognized, File E107041, UL 916, Energy Management Equipment, UL1995,
Heating and Cooling Equipment; FCC Compliant to CFR47, Part 15, Subpart B, Class B
Canada:
UL Recognized, File E107041, CSA 22.2 No. 236, Signal Equipment Industry Canada,
ICES-003 – Recognized
