Specifications and Requirements
Specifications
iSTAR Edge G2 Specifications
Environmental
Operational Temperature 32° F (0° C) to 120° F (49° C)
Electrical
Power 12 VDC, 5 A max
24 VDC, 5 A max
PoE, PoE+ (PoE/PoE+ module must be set to 24 V)
Auxiliary Power 12 VDC, 350mA
Wiegand Ports
12 VDC, 750 mA max each
Reader Output control
(red, green, yellow, beeper)
Open drain
10 mA max
Reader Input Lines (D0, D1) Low Level <0.8 V
High Level 4.0 - 5.25 V
Reader Output Voltage 12 VDC
RM / RS485 Reader Ports 12 VDC, 1.2 A each
Relay Ports 30 VDC, 3.0 A (Dry)
12/24 VDC, 750mA (Wet) Voltage is same as source voltage minus current
switch drop.
All outputs are Class 2 power limited.
Total port output limited by overall board maximum (5A minus board electronics).
Maximum loading must not exceed 4.5 A.
Table 2:Environmental and Electrical Specifications
Power
The iSTAR Edge G2 is powered by a UL 603 or UL 2610 External Power Supply, such as the Software House apS or a
Power over Ethernet (PoE) injector with a UL listed surge protector, evaluated to UL 1449.
A PoE module can be used with the following injectors:
■ POE125U-4-HP-R
■ POE36U-1AT-R
3
