Installation Guide 11
Issue Number: 2 www.johnsoncontrols.com
Safety information Rating data Mechanical installation
Electrical installation
Operation Technical specifications UL listing information
4 Electrical installation
4.1 Drive details
Figure 4-1 Power connection detail
*Ground connection must be made using UL listed 4mm (0.157 in) ring lug
T1/U terminal (Red wire)
T2/V terminal (Blue wire)
T3/W Terminal (Black wire)
Optional
connection
Fuses
Mains supply
L2/S
L1/R
T1/U
T2/V
T3/W
Ground
connection*
Supply
ground
