Installation Guide 9
Issue Number: 2 www.johnsoncontrols.com
Safety information Rating data
Mechanical installation
Electrical installation Operation Technical specifications UL listing information
3 Mechanical installation
Figure 3-1 Basic drive dimensions
The drive can generate and dissipate significant heat. Mount the drive through a metal
mounting surface. Mounting the drive on surfaces made of wood or other heat-
sensitive material may result in damage to the mounting surface.
mm (7.0in)177.8
mm (6.5in)165.1
mm (4.68in)119.1
mm (2.66in)67.7
