VMA1400 Series Overview and Engineering Guidelines Technical Bulletin 8
N2
N2
Network
Control Unit
(NCU)
Operator Workstation
Network
Control
Module
(NCM)
Ethernet LAN
DX9100
TC9102
VMA1400
AHU
DX9100
VAV
Room
Sensor
Laptop
Room
Sensor
UNT
Unitary
Controller
(UNT)
V
MA1400
V
MA1400
Zone
Bus
CablePRO
Converter
UNT
VMAMTSY6
N30
N30
Zone
Bus
Palm Compatible
Handheld Device
™
CVTPRO
Converter
Figure 2: VMA in Metasys Network Diagram
