Johnson Controls Y20EBD Series User Manual

M Motor Actuators
—
Y20EBD Valve Linkage for M100 Motor Actuators 5
Installation Procedures
• screwdriver, small blade
• screwdriver, medium blade
• pliers
• wrench, adjustable, medium
• socket wrench, 3/8 inch drive
4
12
2/3
8
13
10
9
7
1
11
5/6
14
Y20D1-01
Item Description Quantity Item Description Quantity
1
Mounting Bracket Assembly 1
8
Washer (High Temp) 4
2
Valve Bushing, 3/4 in. Not
Grooved
1
9
Hex Nut, 1/4-20 4
3
Valve Bushing, 1 in. Grooved 1
10
Valve Stem Connector 1
4
Yoke Nut 1
11
Rack Subassembly 1
5
Hex (Jam) Nut, 1/4-28 1
12
Gear Subassembly 1
6
Hex (Jam) Nut, 3/8-20 1
13
Washer, Black 2
7
Hex Cap Screw 4
14
Screw 2
Figure 1: Kit Components
Tools Needed
Kit Includes
