Johnson Controls YICM008B21S User Manual

SM-18003
5-29
EXTERNAL INPUT/OUTPUT AND FUNCTION SETTING
(58) Automatic Reset Temperature for Heating (F6)
ThisfunctionisutilizedtosettheautomaticresettemperatureforHEAToperation.
Thesettingconditionsandtheautomaticresettemperatureforheatingareasfollows:
(59) Operation Stoppage Prevention by Wired Controller Operational Error (F7)
Thisfunctionisutilizedtopreventtheaccidentaloperationalstoppagecausedbyinadvertently
pressing(ON/OFF)onthewiredcontroller.Whenthisfunctionisvalid,theoperationisstoppedby
pressing“
”(ON/OFF)buttononthewiredcontrollerformorethan3seconds.However,theenabling
methodisnotchanged.
Operation Lock (60) to (63)
Fouroperationlockfunctionsareavailableasshownbelow.
Thesefunctionsareutilizedtorestricteachswitchoperationfromthewiredcontroller.
Whenthesefunctionsarevalid,modicationofeachfunctionisprohibited.
Alloperationlockfunctionsarevalid(“01”setting)beforeshipment.
Eachswitchoperationbecomesunavailablebypressing“
”and“Back/Help”(return)buttons
simultaneouslyformorethan3secondswhenthesefunctionsaresetas“01”.Theindication“ ” (operation
lockindicator)isindicatedonthewiredcontroller.If“ ”and“Back/Help”(return)switchesarepressed
simultaneouslyformorethan3secondsduring“ ”(operationlockindicator)isindicated,“ ” indication
isturnedOFFandeachswitchoperationisavailable.Thesefunctionsaretorestricttheoperationsof
thewiredcontrolleronly.Ifoperationispreformedfromthecentralizedcontroller,thecommandfromthe
centralizedcontrollerisgivenpriority.
(60) Lock Function for Operation Mode Selection (F8)
(61) Lock Function for Temperature Setting (F9)
(62) Lock Function for Fan Speed Selection (FA)
(63) Lock Function for Swing Louver Operation (Fb)
SettingCondition SettingTemperatureforAutomaticReset
62(17) 62
o
F (17
o
C)
64(18) 64
o
F (18
o
C)
66(19) 66
o
F (19
o
C)
68(20) 68
o
F (20
o
C)
70(21) 70
o
F (21
o
C)(Factory-Setting)
72(22) 72
o
F (22
o
C)
74(23) 74
o
F (23
o
C)
76(24) 76
o
F (24
o
C)
77(25) 77
o
F (25
o
C)
78(26) 78
o
F (26
o
C)
80(27) 80
o
F (27
o
C)
82(28) 82
o
F (28
o
C)
84(29) 84
o
F (29
o
C)
86(30) 86
o
F (30
o
C)
